Parametre
| VT-320 | VT-400 | VT-600 | VT-800 | VT-1000 | |
|---|---|---|---|---|---|
| Základné informácie | |||||
| Max. točný priemer | Φ450mm | Φ550mm | Φ750mm | Φ950mm | Φ1150mm |
| Max. sústružený priemer | Φ320mm | Φ450mm | Φ600mm | Φ800mm | Φ800/Φ1000*mm |
| Max. výška sústruženia | 400mm | 420mm | 600mm | 750mm | 800mm |
| Skľučovadlo | |||||
| Typ skľučovadla | hydraulic | hydraulic | hydraulic | hydraulic | hydraulic |
| Priemer skľučovadla | 10"/254inch/mm | 12"/305inch/mm | 21"/533 , 18"/457*inch/mm | 21"/533 , 24"/610*inch/mm | 32"/800inch/mm |
| Vreteno | |||||
| Max. otáčky skľučovadla | 2500rpm | 2500rpm | gearbox*, 1000rpm | gearbox*, 1500rpm | gearbox*, 1200rpm |
| Výkon pohonu vretena | 15 / 18kW | 15 / 18kW | 15 / 18, 18,5 / 22*kW | 40/30/22*kW | 40/30/22*kW |
| Kužeľ vretena | A2-8 | A2-8 | A2-11 | A2-11/A2-15* | A2-15 |
| Nástrojová hlava | |||||
| Polomer optáčania | 100mm | 125mm | 160mm | 160mm | 160mm |
| Počet nástrojov | 8, 12* | 8, 12* | 8, 12* | 8, 12* | 8, 12* |
| Max. upínacií kvadrát | BMT55*, linear 25x25mm | 32 x 32mm | BMT65*,32x32mm | BMT65*, 32x32mm | BMT65*, 32x32mm |
| Pojazdy | |||||
| Pojazd v osi X / Z | 300(+250:-50)/400mm | 350(+300:-50)/450mm | 450(+400:-50)/600mm | 500(+450:-50)/780mm | 550(+520:-30)/850mm |
| Rýchloposuv v osi X / Z | 15 / 18m/min | 15 / 18m/min | 15 / 18m/min | 16/16m/min | 16/16m/min |
| Rôzne | |||||
| Príkon stroja | 18kVA | 22kVA | 35kVA | 55kVA | 55kVA |
| Rozmery stroja (dxšxv) | 1600x2000x2200mm | 1900 ×2100 ×2900mm | 2200 ×2300 × 3300mm | 2200 ×3800 × 3400mm | 2400 ×4300 × 3800mm |
| Hmotnosť stroja | 5 500kg | 7500kg | 11 500kg | 12000kg | 14000kg |
| *Za príplatok | Zmena technických parametrov vyhradená |
